5 Ton Top Running Single Girder Overhead Crane Industrial Bridge Hoist System

Product Description

LH electric hoist bridge crane is designed according to the standard of JB/T3695-1994 manufacturing, and CD I,MD I and other forms of fixed supporting the use of electric hoist double girder overhead traveling crane, trolley girderstructure in the track laying, its suitable weight is 1-32t, the applicable span is 7.5-31.5 meters, the working environment temperature in -25-+40 the temperature range of. This product is a general purpose crane, for mechanical manufacturing, assembly, warehouse application frequency is low or the rated lifting weight lifting timesfewer places. Advantages: good stability, effective use of make full use of the workshop headroom achieve higherlifting height, moderate prices; disadvantages: working level low, not suitable for heavy workshop. The crane is provided with a bottom surface, control room, remote control of three kinds of operating mode, control room and is provided with an end face and side door two forms, for users to choose to use.
The product specification is the method such as the following:
(1) ground handling
Example: lifting weight: 3T, span: 10.5m, lifting height 6m, said method working level A3: LH310.56DA3
(2) the operating room manipulation (split control room KS and closed control room BS)
Example: lifting weight: 5T, span: 16.5m, lifting height 6m, working level A3, open control room manipulationrepresentation method: LH516.56KSA3
(3) remote control

Example: lifting weight: 10t, span: 13.5m, lifting height 6m, said method working level A3: LH1013.56YA3
