CE Certified Single Girder Gantry Crane - 5-20 Ton (Europe/UK Market)
$5000.00 1 set
Qingdao Shanghai
L/C T/T
New
MH
CE, ISO9001
DALI
General manufacturing,Metal production industry,Renewable energy industry
Product Description
Product introduction
Usage(Application):
MH gantry crane is widely used in varied industries, like material stocks area, cement plant, granite industry, engineering industry, construction industry, shipping yards, road sides, mines, steel plant, concrete girder yard, etc.
Single girder gantry crane is a kind of track traveling midlight type crane, used together with CD, MD, HC model electrical hoist, according to the shape, it also divided into MH type and MHLP type gantry crane.
MH type single girder gantry crane has box type and truss type, the former have good techniques and easy fabrication, the latter is light in dead weight and strong in wind resistance. For different usage, MH gantry crane also has cantilever and noncantilever gantry crane. If have cantilevers, the crane can load the goods to the crane edge through the supporting legs, which is very convenient and high efficiency.
MHLP type single girder gantry crane is Ltype partial hanging gantry crane, with small size and light duty, special for putting steel pipes, girders, or other long materials into the special place, widely used in steel plant, concrete girder yard.
Single girder gantry crane specification:
| Capacity(t) | 1t,2t,3t,5t | 10t | 16t | 20t |
| Span(m) | 6.5m---35.5m | |||
| Lifting height(m) | 3m---18m | |||
| Control mode | Pendant control,wireless remote control,cabin control | |||
| Lifting speed(m/min) | 2.8 , 8 ,8/0.8 | 2.3 , 7 ,7/0.7 | 4 , 4/0.4 | 3.5 3.5/0.35 |
| Travelling speed(m/min) | 20,30,45(Inverter) | |||
| Service class(work grade) | a) M3: used in places of mild service, such as workshop and warehouse. b) M4: used in places of Medium service such as assembly and depot. | |||
| Cantalever | One side or two side cantilever | |||
| Supply power(three phase power) | 380V 50HZ 3Phase (according to user require) | |||
| Hoist type | Wire rope or chain hoist ,single or double speed | |||
| Working ambient temperature | -20 °C~ <55°C. | |||
| Note | It's not suitable for lifting blazing & melting metal or toxicant as well as explosion-proof or insulating working conditions. | |||
Company Information
Zhangjiagang Dali Crane Machinery Manufacturing Co., Ltd. is located in the welfare industrial zone of Jinfeng Town, Zhangjiagang City, a national health city. The company's predecessor was founded in 1975 and has been working in the machinery industry for many years. It is mainly engaged in the manufacture and installation of lifting and transportation machinery and metallurgical equipment.Dali Cranes meet the factory, workshop, port, mining, waste disposal, goods scattered, petrochemical, aerospace, military and other industries of universal bridge crane, overhead crane, eot crane, door crane, universal gantry crane,rail mounted container gantry crane four link type portal crane, quayside container crane, crane, gantry crane, ship loader, grab bucket ship unloader and other types of hydraulic crane technical requirements.
Our Services
` 24 hours professional technical support
` Free spare parts supporting for one whole year after signing order
` Mechanical and electrical engineer available for oversea service!
` Special customized according to the client's request!
Shipping and payment
Electric parts are packed by high quality plywood crate, to reduce distortion in conveying.
2. Main beams, end beams and trolly/winch are packed by plastic woven cloth. It can reduce abrasion during the transportation.
3. If the size are suitable for container ship, usually by container.
4. Big size, usually by bulk ship or by container after truncation.
5. Transport ways are based on reducing cost & keep safety.
