F23-a++ 8 Channel Single Speed Industrial Radio Remote Control System

$150.00
1 set
Qingdao Shanghai
L/C T/T
New
F23-A++
CE, ISO9001
ELECTRONIC
General manufacturing

F23-A++ 8 channel single speed Industrial Radio Remote Control System

Specification:

1. More than 10 years researching and exporting experience in Radio Remote Control industry.

2. Well and high quality control, all working process according to ISO9001:2008.

3. CE, FCC & ISO certificates.

4. One year warranty.

5. Sample order acceptable.

6. OEM acceptable.



Brief Introduction:



Application

Hoist, crane,overhead crane

Frequency

VHF:310.0325~331.165Mhz,UHF:433.050-434.790MHZ

Frequency generation:

Crystal (plug in)

Channel

80

Channel Spacing

0.2675MHz

Control motions

8

Control distance

Up to 100m

Certificates

CE, FCC, ISO

Number of push button

8 Single speed push button +1 start+1stop

Unique code

Over 4.3billon unique ID codes .

Working temperature

-35°C ~ +80°C

Enclosure protection class

IP65

Transmitter power

AA-size batteries

Receiver power

AC 380v/220V/110v/48v/ 36v/24v/12v or DC12V

Output capacity

Full sealed relay output with 5 amperes

Model

can be set normal,toggle,interlock or non-interlock

Material

glass fiber



Photos:
F23-a++ 8 Channel Single Speed Industrial Radio Remote Co<em></em>ntrol System

Standard Configuration:


1. One transmitter;

2. One receiver;

3. One 1m cable connect with receiver



4. One operation and maintain manual.

Packing & delivery

F23-a++ 8 Channel Single Speed Industrial Radio Remote Co<em></em>ntrol System




Features:

*10 single speed push button (3,4 key are useless)

*Control points are up to 8.

*With the battery voltage alarm device to cut off the circuit when voltage is insufficient.

*With the Rotate key switch to guarantee the safety.

*Set the internal functions by computer interface.

*Up/down, east/west, south/ north push button can be set mutual inhibition or not.

*Power button can be set start, speed up, jump strokes, ordinary etc.

*Spare 1-2 key can be set ordinary, interlock, jump strokes, switch etc.



If you are interested in our products, pls feel free to send inquiry to us
