F24-8d Wireless Remote Control

F24-6D High Quality Wireless Remote Control EOT Crane remote control

Brief introduction:
1. 6 dual speed pushbuttons+STRAT
2. Control distance reach to 100m.
3. The total control motions can reach to 10.
4. Glass fiber and engineering-plastics make the cover strong. IP 65, water-proof.
5.Full set include one transmitter, one receiver, one protection bag, one wire and the specifications.
6. Wide receiver voltage can meet different requirement

1. Technical specifications
 1.1 Basic informations:



1.2 Transmitter specifications
1. Dimensions: 246*75*46mm
2. Weight: 350g
3. Material: glass-fiber
4. Protection degree: IP65
5. Power supply: DC 3V (2AA Batteries)


1.3 Receiver specifications
1. Power supply: AC380V/36V/220V/110V/48V/24V or    AC12V/DC12V (±20%)
2. Dimensions: Size:200*165*107mm
3. Weight: 550g
4. Material: glass-fiber
5. Protection degree: IP65

2. Standard configuration:
        One transmitter ;
        One receiver;
        One 1m cable connect with receiver
        One operation and maintain manual .

3.  Application of remote controller:
Widely applied for lifting equipments, construction machinery, cargo loading/unloading machines, water supply system, data transmission, the iron-smelting and steel-making, the automobile manufacturing, papermaking and chemical industry, steel structure processing, galvanization, shipbuilding, railroad, bridge, tunnel construction and other equipments and sites which can be worked by radio controls.

4. Products Features:
*6 Dual speed push buttons +one EMGS button+ one START button+ one STOP button + one SWITCH
* control points up to 10
* With the battery voltage alarm device to cut off the circuit when voltage is insufficient.
* with the Rotate key switch to guarantee the safety.
* set the internal functions by computer interface
* up/down,east/west,south/north push button can be set start ,close,speed up,jump strokes,ordinary etc


5. Notes:
The LED on the front of the transmitter indicates the condition of the batteries.  It will flash green during operation if the battery power is sufficient, and will flash red if the battery power is low.  If the LED is flashing red, or if the operation becomes erratic, or will only work from a short distance, replace both batteries with new AA alkaline batteries.



 Packing & Delivery:

6 sets per carton
carton size: 77*48*34cm
3-5 working days after receiving the full payment
