Waterproof Mechanical Grab Bucket for Efficient Underwater Material Handling

Waterproof Mechanical Grab Bucket for Efficient Underwater Material Handling

$4500.00

Min. Order: 1 set

Port: Qingdao Shanghai

Payment Terms: L/C T/T

Transport Package:

Conditions: New

Model: Grab Bucket

Certifications: CE, ISO9001

Brand: Enjue

Application: General manufacturing

Contact Supplier

Add to Wish List

Max. Lifting Capacity: t

Max. Lifting Height:

Span:

Voltage:

Working Duty: M3-M5

Color: Customized

Brand/Trademark: Enjue

Model: Grab Bucket

Origin: 中国

Warranty: 1 Years

Product Introduction:
The dredging grab is an effective tool capable of performing salvage and dredging operations underwater, encompassing the removal of silt, hard clay, iron-plated sand, blasted rocks, and even sunken ships. It finds extensive application in dredging projects across rivers, harbors, docks, and other aquatic environments, playing a pivotal role in improving navigational conditions and enhancing the navigability of waterways.
Clamshell Dredging Grab Bucket, Mechanical Dredging Grab Bucket for Underwater Dredging about the dredging grab features

Detailed Photos

Product Parameters

Material	Dead weight(t)	Dimension(mm)					Pulley Dia(mm)	Ratio	SWL(t)
			1	2	3	4	5
1 (00)	sludge	4	2380	3458	3533	4083	1320	560	5	6
1.5(00)	Stiff mud	6.5	3020	4039	3772	4532	1500	560	5	12
5(300)	sludge	8	3260	5042	4502	5280	1820	650	4	20
5(150)	Stiff mud	13	3740	5450	4942	5916	2012	800	5	30
5.5(00)	Rock	35	3960	5812	5614	6565	2150	880	6	55
4(250)	Rock	25	3840	5657	5748	6715	1950	880	6	45
5(250)	Rock	36	3600	5947	6164	7125	1940	880	6	45
8(250)	Stiff mud	28	4040	6632	6494	7364	2102	880	6	45
5(250)	sludge	32	3960	5734	7194	8167	1940	880	5	55
16(250)	sludge	48	5130	7712	7415	8724	2954	1045	6	70
8(250)	sludge	60	4130	6695	7189	7753	2530	1045	7	80
11(250)	Stiff mud	55	5120	7780	7553	8924	2420	1045	7	55
9(250)	shipwrecks	110	5465	7202	8666	10264	3000	1500	7	110

Our Advantages

Clamshell Dredging Grab Bucket, Mechanical Dredging Grab Bucket for Underwater Dredging

Company Profile

Clamshell Dredging Grab Bucket, Mechanical Dredging Grab Bucket for Underwater Dredging

Certifications

Our Main Product
We have more different products for you to choose from, which can be customeized according to your needs, you can also compare several, I am very confident in our products.

Clamshell Dredging Grab Bucket, Mechanical Dredging Grab Bucket for Underwater Dredging

Packaging & Shipping

CUSTOMER VISITING Clamshell Dredging Grab Bucket, Mechanical Dredging Grab Bucket for Underwater Dredging about Clients Comments and After-Sale Services
