JM Slow Speed Electric Winch, 15 Ton Capacity, 200m Rope Capacity, 5-20 m/min

• Introduction:

This trolley hoist or crab hoist is a double girder crane wire rope hoist which is mounted on a trolley frame. It is composed of a hoist and a trolley frame, and the frame is also driven by motors and travels on rails fixed on the 2 crane girders. This trolley hoist is made according to European FEM standards and Germany DIN Stands.

• Parameter:

• Capacity: 3t~80t

• Lift Height: 6m~36m

• Work duty: M5

• Traveling speed: 2~20m/min

• Lift speed: 0.8/5.0m/min

• Features:

• Impact structure, low headroom, lightweight, modular design, and precise positioning, etc.

• Steel structure optimization design

• Light-Weight, small wheel load

• Small blind spot

• Reduce the height and cost of the workshop

• Advanced welding technical, high rigidity

• Free maintenance

• High strength hook of German DIN standard

• Modular design for wheel group

• Smooth transition end beam

• Security and efficiency remote control operating system

• Components flexible combination

• Determinate structure trolley frame

• Hard gear reducer from Germany

• Hoist Motor:

• Rugged 12/2-pole cylindrical-rotor motor (selection of frequency conversion)

• Less vibration, quiet running;

• Thermal contacts to protect against overheating;

• Designed for extended operating periods, classified in accordance with FEM;

• IP 54 enclosure.

• Brake:

• DC disc brake with brake release monitoring (optional)

• Min. safety factor of 1.8;

• Rapid response through integrated brake module.

• Control System:

• Conventional contactor control;

• Frequency conversion operation;

• Electronic module for control of time functions;

• Overload protection fitted as standard for increased safety;

• Control by means of DST control pendant (optional);

• Ergonomic and rugged design with 7 or 9 buttons;

• Emergency off switch fitted as standard;

• Accurate 2-pole rotating limit switch.

• Rope Guide:

• 1. Generously dimensioned drum for long rope service life;

• 2. Precisely machined rope grooves;

• 3. Rope guide made of heavy duty composite material;

• 4. Reliable fleet angle up to ±4 degree without physical contact between rope and rope guide.

• Gearbox:

• 3-stage, helical gear reducer;

• Low running noise;

• Lifetime lubrication.

• Gearbox:

• Ergonomically designed and operator friendly;

• Pulley made of special materials with low noise;

• Smooth running.
