Custom Span LX Electric Single Girder Suspension Crane, Up to 5 Ton Capacity

LX Electric Single Girder Suspension Overhead Crane

▪LX single girder suspension overhead crane ( LX Electric single beam suspension bridge crane) is desingn according to the international standard. Together with CD1, MD1 electric hoist as a complete set to load and unload the goods. It's a light duty track traveling crane. The capacity is 0.5t~10t, the span is 3m~16m, the working system is A3 or A4, and the operation method generally choose remote control.

1. LX Electric Single Girder Suspension Overhead Crane Parameters:
▪ Lifting capacity: 0.5ton, 1ton, 2ton, 3ton, 5ton, 10ton
▪ Span: 3m~16m
▪ Lifting height: 6m, 9m, 12m, 18m, 24m, 30m
▪ Lifting speed: 8/0.7m/min
▪ Crane traveling speed: 20m/min, 30m/min
▪ Electric hoist type: CD MD

2.Compare with LD single girder overhead crane, the LX single girder overhead crane has the advantages as below:
▪ Low cost: the design is simple, the main beam suspend the I steel, reduce the factory height and light weight.
▪ Operation safety: the crane design according to the internation industry stander, and the light lifting weight of 0.5ton to 10ton, what’s more, Equipped with overload protection device and the emergency stop button.
▪ Quality: Every equipment will be inspected strictly by the inspection department before deliver to customer, and if have some problem, the special after-sales department will contact you within one work day.
