China 30t Double Beam Eot Overhead Crane with Best Service
$15900.00 1 1
Qingdao
L/C T/T
New
QD
GS, RoHS, CE, ISO9001
Mingdao
General manufacturing,Metal production industry,Renewable energy industry,Paper and wood industry,Power Industry,Mineral industry
High Quality Machinery 30T Double Beam EOT Overhead Crane
PRODUCT FEATURES
-----------
Brief Introduction:
Double girder electric overhead crane has the advantages of compact shape dimension, low building headroom height, light weight,small wheel pressure and so on. It uses together with CD1 or MD1 electric hoist. It is suitable for transporting, assembling ,repairing and load; unload works in mechanical processing workshop,metallurgy auxiliary workshop, storage, yards, power station and so on. It can replace normal double-beam bridge crane and being used in workshop of textile industry and food industry. The work type can be divided into two kinds- light class and intermediate class, the temperature of working environment is -25ºC-40ºC.
Technical Parameters:
| Mechanism | Item | Unit | Result | ||
| Item | |||||
| Lifting capacity | ton | 5-50ton | |||
| Working grade | A3-A5 | ||||
| Span | m | 5-40m | |||
| Working environment temperature | °C | -25~40 | |||
| Travelling mechanism | working speed | m/min | 20-75 | ||
| motor | type | YZR160M2 | |||
| power | kw | 2*0.8 | 2*1.5 | ||
| rotational speed | m/min | 1380 | |||
| Lifting mechanism | lifting speed | m/min | 8/0.8(7/0.7) 3.5(3.5/0.35) 8(7) | ||
| lifting height | H(m) | 6 9 12 18 24 30 | |||
| travelling speed | m/min | 20 30 | |||
| working system | A3-A5 | ||||
| power source | 380V 3PH 50HZ | ||||
PRODUCT DETAILS
-----------
♦ This product has two operational methods, ground(pendent controller /remote controller) or operational cabin room .
| Lifting Mechanism | Wire Rope Hoist (CD/MD/European Type) Lift Speed: single/dual Travel speed:variable Function: Lift goods Electric Winch |  |
| Main Girder/Beam | Double Rigid welded box type Module design Travel speed:variable Function:bearing load Material: Q235/345 |  |
| End Carriages | Rigid welded box type Module design Gear motor &reducer Function: Push crane run forward or reverse Materials:Q235/345 |  |
| Control | Ground pendent button Radio Remote control Cabin control |  |
| Electric parts | Circuit breaker/ AC contactor etc electric parts use Schneider /Siemens/ABB/DELIXI Etc famous brand |  |
Advantages of a single girder design:
Less expensive due to a simpler trolley design, reduced freight costs, simplified and faster installation, and less material for the bridge and runway beams
Most economical option for light to medium-duty cranes
Lower loads on the building structure or foundations due to a reduced deadweight. In many cases, it can be supported by existing roof structure without the use of additional support columns.
Better hook approach for both trolley travel and bridge travel
Easier to install, service, and maintain
Ideal for workshops, warehouses, material yards, and manufacturing and production facilities
Lighter load on runway rails or beams means less wear on the beams and end truck wheels over time
Great for facilities with low headroom
Safety Devices for overhead crane:
To guarantee the normal operation of crane and avoid the personal casualty and mechanical damage, the safety device we provide are not only the electric protective devices or alarm bell but also other equipments as following:
1.Overload Limit Switch
2.Rubber Buffers
3.Electric Protective Devices
4.Emergency Stop System
5.Voltage Lower Protection Function
6.Current Overload Protection System
7.Rail Anchoring
8.Lifting Height Limit Device
