VH Series Wire Rope Hoist 20ton Lifting Height 6m

$6050.00

Min. Order: 1 set

Port: Qingdao Shanghai

Payment Terms: L/C T/T

Transport Package:

Conditions: New

Model: VH

Certifications: CE, ISO9001:2000

Brand: MIT

Application: General manufacturing

Max. Lifting Capacity: 20 t

Max. Lifting Height: 20m

Span:

Voltage: 380v/440v/customized

Working Duty: M3-M5

Color: Customized

Brand/Trademark: MIT

Model: VH

Origin: 中国

Warranty: 1 year

Detail Specification
1. Highly Reliable Braking System With Automatic adjusting device :
The break is equipped with an automatic adjusting device to apply brake torque in proportion to the amount of linning abrasion.
The douuble braking system consists of the main brake and auxxiliary brake unit.
2. Hoisting Motor with a Termal Protector :
The hoisting motor automatically stops when sensing the heat of the motor coil in order to protect the motor from buring damage caused by heat due to overwork.
3. Efficient Maintenance is Possible :
The starting time counter in the control box facilitates checking of the lifetime of consumable parts.
The gear inspection window in the control box allows visual checks of the condition of the gear teeth surface and lubrication to some degree.
The pumch mark on the hook indicates the reference point for the hook inspection of deformation.
The inspection of the rope end is easy.
Technical Parameters (Size Specification)

Single Girder Wire Rope Hoist
Specifications
Capacity(t)				2	3.2	5	7.5	10	15	20
Hoisting lift(m)				6 and 12		8 and 12
Hoisting	Speed (m/min)		50Hz	8.4	7.5	6.7	6.0	5.0	5.0	4.2
	Motor	(KW)	60Hz	10	9	8	7.2	6.0	6.0	5.0
			50Hz	2.9	4.2	5.9	7.9	8.8	6.7?2	7.5?2
			60Hz	3.5	5	7	9.5	10.5	8?2	9?2
	No.of poles			4			4
Traversing	Speed (m/min)		50Hz	21			14
			60Hz	25			17
	Motor	(kw)	50Hz	0.30	0.45	0.63	0.47?2	0.47?2	0.7?2	0.7?2
			60Hz	0.36	0.55	0.75	0.56?2	0.56?2	0.84?2	0.84?2
	No.of poles			4			6		4
Wire rope	No.of poles				2		4
	Composition			6?Fi(36)-B						6?Fi(36)IWRC-B
	Diam.(mm)			?11.2	?14	?12	?14	?16	?20	?22.4

Double Girder Wire Rope Hoist
Table of Dimensions
Model		2W-12TD	3W-6TD	3W-12TD	5W-9TD	5W-12TD
Trolley type		2DTs	3DTs	3DTs	5DTs	5DTs
Capacity(t)		2	3.2		5
Approx. dimensions (mm)	L	12000	6000	12000	9000	12000
	H	310	360		560
	K	430	480		500
	R	900	650	950	900	1150
	F	455	430		530
	E	425	450		550
	W	650	650		850
	A	835	755	915	845	955
	B	675	570	730	690	800
	?d	56	71		90
	Q	40	51		55
	?M	160	160		160
	?N	190	190		190
	G	26	26		26
	e	350	325		425
	a	36	42		58
