High Speed Low-Voltage Track Transfer Cart
$5000.00 1 set
Qingdao Shanghai
L/C T/T
New
KPW
CE, ISO9001
ruixing
General manufacturing
The description of assembly line automation electric flat car
Assembly line automation of electric flat car for low voltage track type, using frequency and encoder, the combination of precision positioning, call the wireless call system, PLC and intelligent security scanner, auxiliary hydraulic radial docking station, single roller conveyor artifacts, realize remote call, run automatically, automatic docking, automatic blanking, fully automatic unmanned operation.
Product parameter
| Modle | Load capacity (ton) | Overall size ( L*W*H) | Track inside distance(mm) | Running speed(m/min) | Running distance(m) | Power(v) | Recommended steel track |
| KP-5-1 | 5 | 3500×2000×600 | 1435 | 0-25 | 10-200 | 380V | P24 |
| KP-10-1 | 10 | 3500×2000×600 | 1435 | 0-25 | 10-200 | 380V | P24 |
| KP-20-1 | 20 | 4000x2200X650 | 1435 | 0-25 | 10-200 | 380V | P38 |
| KP-30-1 | 30 | 4500×2200×650 | 1435 | 0-25 | 10-200 | 380V | P38 |
| KP-50-1 | 50 | 5000×2500×750 | 1435 | 0-25 | 10-200 | 380V | P43 |
| KP-75-1 | 75 | 6000×2500×850 | 1435 | 0-25 | 10-200 | 380V | P50 |
| KP-100-1 | 100 | 6500×2800×900 | 1435 | 0-25 | 10-200 | 380V | P50 |
| KP-150-1 | 150 | 8000×3000×1000 | 1800 | 0-15 | 10-200 | 380v | P50 |
| KP-200-1 | 200 | 8000×3000×1100 | 1800 | 0-15 | 10-200 | 380V | QU80 |
| KP-250-1 | 250 | 10000×3200×1200 | 2000 | 0-15 | 10-200 | 380V | QU80 |
| KP-300-1 | 300 | 10000×3200×1200 | 2000 | 0-15 | 10-200 | 380V | QU100 |
| KP-500-1 | 500 | 12000×3500×1500 | 2500 | 0-15 | 10-200 | 380V | QU120 |
Production Supply Scope
Machining industry, automobile manufacturing, steel companies, smelting, casting, logistics, molds, engineering, tunnels, aviation, medical equipment, etc.
Product advantages of our company
1, Our company is the professional manufacturers of electric transfer cart in Henan province , more experience, more exquisite technology. Can be customized according to different needs of users.
2. The series of electric transfer cart produced by our company are new electric transfer cart. According to the principle of heavy crane adopts box bearing beam structure, which is better than the old transfer cart in rigid strength, greater local bearing capacity, higher safety factor, convenient for maintenance, beautiful appearance and other advantages.
3, Our company's products have one of the biggest advantages: high parts and components of the product interchangeability (in all parts of the country operating crane operating department can be purchased, to avoid the traditional product parts must be bought in the manufacturer), can be save a lot cost for the using company.
4. The whole process of product design and manufacturing shall be ensured under the control of ISO9001 quality system standard.
5. Our company provides free technical support and lifelong after-sales service for users.
