10 Ton Marine Electric Chain Hoist – High Lifting Speed & Overload Protection
$665.00 1 set
Qingdao Shanghai
L/C T/T
New
TH276
CE, ISO9001
Taihang
General manufacturing
Marine 1 Ton 2 Ton 5 Ton 10 Ton 3ton 3 Phase Electric Chain Hoist
Electric Chain Hoist is a light and small lifting equipment. It consists of an electric motor, transmission mechanism, and sprocket. All are produced according to international standards. The body is beautiful in appearance and durable. The internal gears are all quenched at high temperatures, which increases the wear resistance and toughness of the gears. The most advanced international technology is used, and the workmanship is fine and the gears are tightly fitted.
1, Extensively used in factories, workshops, warehouses, and many other occasions to hoist materials directly,
2, Installed on the straight or curved I-steel beam of Single-girder Cranes to lift goods.
3, It can also be used together with an Electric Hoist Double-beam, gantry crane, and slewing cranes to hoist different items and so on.
4. It has so many applications usages just for its advantages, such as tight structure, convenient operation, lightweight, wide common use, and so on.
Model | CD1/MD1(CD1Y/MD1Y) | |||||
Capacity(t) | 0.5 | 1 | 2 | 3 | 5 | 10 |
JNorm working level | M3 | M3 | M3 | M3 | M3 | M3 |
Hoisting height(m) | 6/9/12/ 18/24/30 | 6/9/12/ 18/24/30 | 6/9/12/ 18/24/30 | 6/9/12/ 18/24/30 | 6/9/12/ 18/24/30 | 6/9/12/ 18/24/30 |
Hoisting speed(m/min) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 7(7/0.7) |
Operating speed(suspended type) (m/min) | 20(20/6.7) 30(30/10) | 20(20/6.7) 30(30/10) | 20(20/6.7) 30(30/10) | 20(20/6.7) 30(30/10) | 20(20/6.7) 30(30/10) | 20(20/6.7) 30(30/10) |
Multiplying power of chain wheel | 2/1 | 2/1 | 2/1 | 2/1 | 2/1 | 4/2 |
Type and power of hoisting electric motor(kw) | ZDY11-4 (0.8) | ZDY22-4 (1.5) | ZDY31-4 (3) | ZDY32-4 (4.5) | ZDY41-4 (7.5) | ZDY51-4 (3) |
ZDSI-0.2/0.8(0.2/0.8) | ZDSI-0.2/1.5(0.2/1.5) | ZDSI-0.4/3(0.4/3) | ZDSI-0.4/4.5(0.4/4.5) | ZDSI-0.8/7.5(0.8/7.5) | ZDSI-1.5/1.3(1.5/1.3) | |
Motor type and power(suspended type)(kw) | ZDY11-4(0.2) | ZDY11-4(0.2) | ZDY12-4(0.4) | ZDY12-4(0.4) | ZDY21-4(0.8) | 2xZDY21-4(0.8) |
Level of protection | IP44/IP54 | IP44/IP54 | IP44/IP54 | IP44/IP54 | IP44/IP54 | IP44/IP54 |
Type of I-steel track | 116a~128b | 116a~128b | 120a~145b | 120a~145b | 125a~163b | 140a~163b |
Minimum turning radius(m) | 1/1/1 /1.8/2.5/3.2 | 1/1/1.2 /1.8/2.5/3.2 | 1.2/1.2/1.5 /2.0/2.8/3.5 | 1.2/1.2/1.5 /2.0/2.8/3.5 | 1.5/1.5/1.5 /2.5/3.0/4.0 | 1.5/1.5/1.5 /2.5/3.0/4.0 |
Net weight(kg) | 135/140/155 /175/185/180/ | 195/190/205 /220/235/255 | 250/265/300 /320/340/360 | 320/340/350 /380/410/440 | 590/630/650 /700/750/800 | 820/870/960 /1015/1090/1125 |
Product Parameters
Our Advantages
1. Our Shipyard: Ningbo Zhenhe shipyard, and now Taihang is the branch representative of our yard.
2. Our founding team has experience of more than 15 years in shipbuilding and ship repair with our engineer and designer.
3. Equipment quality guarantee: based on shipyard feedback, we built up a manufacturer file to ensure the good quality of the products. Also, we can send our engineers to help our clients to install and test this exported equipment.
4. We are a second-hand ship broker to help you find the satisfied used different kinds of vessels.
5. We can provide the CKD kits and one-stop service based on our laser-cutting machine and purchase ability
6. We have a very professional design and technical team to work out the perfect plan for our clients and help to solve any matters with pre-sale and after-sale.
7. Customer Distribution: Tanzania, Rwanda, India(Mumbai and Kolkata), Suva, Portugal, Russia, Netherlands, Iceland, Denmark, Malaysia, Mexico.......
