1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution 1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution
1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution 1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution
1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution 1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution
1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution 1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution
1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution 1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution

1-10 Ton Single Girder EOT Crane – Compact & Efficient Workshop Solution

$6000.00
1 set
Qingdao Shanghai
L/C T/T
New
LD
CE, ISO9001
Weiying
General manufacturing,Metal production industry,Renewable energy industry
Contact Supplier
Add to Wish List
32 t
30m
7.5-31.5m
380v/440v/customized
A3,A4,A5
Yellow,Customized
Weiying
LD
中国
1 Years

  Cheap Price Electric Overhead Hoist Crane
Product desription:
Hoist crane 5 ton single girder is widely used in factory
store house and cargo yard, forbid to be used in corrosive and explosive places.This crane belongs to light duty crane, can be used with CD1 and MD1 hoist. Lift capacity is from 1 ton to 20 tons, spam from 7.5m to 22.5m, working condition is A3-A5, working temperature is -25°C to +40°C.
Advantage :
1. Low dead weight- computer optimization design box beam
2. The shell of hoisting motor is adopted to aluminum alloy, light weight, corrosion resisting (IP55), stable lifting and lower noise.
 Advance technology of VVVF control, plane brake inside the body, ABM hardened parallel shaft gear reducer, permanent lubrication,
non need for maintenance
3. Stepless frequency control method make the crane travel stable as well as anti shake
4. Cross trolley traveling motor adopt to 3 in 1 type dual drive, unique no-open gear transmission. Compact structure, lower noise
5. Modularized design electric box, whole imported electric component, anti-phase dislocation,
default phase and over current protect
6. Flashlight door outfit with pendant push button
7. Rotation limit switch device can automatically stop lifting movement when hook reach to both upper and inferior limit


Lifting capacityt5-1016/3.220/532/5
Spanm1822263035182226303518222630351822263035
Lifting heightMainm1011101110111011
Aux/10.511.5101110.8511.85
Working systemA5(intermediate)


Speed		HoistingMainm/min12.5-9.829.79.37.6
Aux/22.319.819.8
Crab travelling39.5-40.439.739.738.6
Trolley travelling46-39.539.5-4039.54039.5484954
Installed powerKW28.1-48.562.371.376.885.596.8108119
Max. wheel loadKN157-286292300301363375333339355410423225235255274284
Power source380v 50Hz 3phase AC
