Vacuum Furnace Using Electrical Railway Ferry Transfer Cart for Industry
$3000.00 1 set
Qingdao Shanghai
L/C T/T
New
KPC
CE, ISO9001
BEFANBY
General manufacturing
Durable Manufacturing Industry Busbar Powered 45 Tons Railroad Transfer Trolley
Busbar powered Wind turbine railway transfer car for warehouse transport,the kind of railway transfer car is powered by busbar,you can put the busbar in the hole, if your on rail transfer car approachs to the wall ,the busbar also can be fixed on the wall ,what we do not only can save the space but could reduce the impair for the ground.Of course ,it can be customized according to your requirement. it is the first choice for the workshop which has been widely used in steel factory.
Features for transfer cart:
1.The safe system are installed to make it safer.
2. Easy operation and low cost.
3. No strict requirement of rails.
4. Customized for you.Custom table size, operating speed,load,etc.Meet your requirements.
5. The sliding wire is limited by the position,it can be installed between the two rails ,The hole should be digged or it can also beplaced in the channel outside the track.
Details Images
Product Parameters
| Model | KPC-2T | KPC-5T | KPC-10T | KPC-20T | KPC-25T | KPC-30T | KPC-40T | KPC-50T | KPC-80T | KPC-100T | |
| Rated load(t) | 2 | 5 | 10 | 20 | 25 | 30 | 40 | 50 | 80 | 100 | |
| Table Size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 6000 | 6500 |
| Width(W) | 1500 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2600 | 2800 | |
| Heigth(H) | 450 | 450 | 500 | 550 | 600 | 600 | 650 | 650 | 800 | 850 | |
| Wheel base(mm) | 1200 | 2500 | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4700 | 4900 | |
| Rai lnner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | |
| Wheel Dia.(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | |
| Wheel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(mm) | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| Motor Power(kw) | 0.8 | 1.5 | 1.5 | 2.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 11 | |
| Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 278.4 | 343.8 | |
| Reference Wight(t) | 2.3 | 3.3 | 3.8 | 5.5 | 6 | 6.3 | 7.2 | 7.6 | 12.1 | 13.9 | |
| Recommend Rail Model | P15 | P18 | P18 | P24 | P38 | P38 | P43 | P43 | P50 | QU100 | |
