Low Headroom Electric Wire Rope Hoist 15-40 Ton - Design for Workshops
$500.00 1 set
Qingdao Shanghai
L/C T/T
New
CD1/MD1
CE, ISO9001
BEFANBY
General manufacturing,Metal production industry,Renewable energy industry
5 Tons Suspension Steel Plate Electric CD1 MD1 Wire Rope Hoist
Wire rope electric hoist is a kind of light small lifting equipment, rated lifting weight 0.25t~ 16t, standard lifting height 6m~30m, rated voltage 380v, non-standard lifting height and voltage can be customized. The working class is M3, can be installed on straight or curved I-beams, can also be used on bridge cranes, gantry cranes or cantilever cranes. Widely used in port, electric power, steel, shipbuilding, petrochemical, mining, railway, construction, and other important industries and infrastructure engineering machinery and equipment.
Details Images
Product Parameters
| Product Model (Support Customization) | 0.5T | 1T | 2T | 3T | 5T | 10T |
| Lifting Height (m) | 6/9/12/18 | 6/9/12/18/24/30 | 6/9/12/18/24/30 | 6/9/12/18/24/30 | 6/9/12/18/24/30 | 9/12/18/24/30 |
| Lifting Speed (m) | 8 | 8 | 8 | 8 | 8 | 7 |
| Operating Speed(m/min) | 20(30) | 20(30) | 20(30) | 20(30) | 20(30) | 20(30) |
| Wire Rope Diameter(mm) | 4.8 | 7.4 | 11 | 13 | 15.5 | 15.5 |
| Workers Steel Rail Model(GB706-88) | 16-28b | 16-28b | 20a-32c | 20a-32c | 25a-45c | 32b-63c |
| Lifting Motor Power(Kw) | 0.8 | 1.5 | 3 | 4.5 | 7.5 | 13 |
| Operating Motor Power(Kw) | 0.2 | 0.2 | 0.4 | 0.4 | 0.8 | 0.8x2 |
| Voltage(V) | 380(220-660) | |||||
| Frequency(Hz) | 50 | |||||
| Phase(ph) | 3 | |||||
