 henan-chongpeng > Supply > Slow speed electric winch
Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed
Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed
Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed
Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed
Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed

Double Drum Electric Winch | 2 x 10-Ton Synchronized Lifting | Low Speed

$1500.00
1 set
Qingdao Shanghai
L/C T/T
New
JM
CE, ISO9001
Chongpeng
General manufacturing
Contact Supplier
Add to Wish List
50 t
30m
380v/440v/customized
M3-M5
Blue,Customized
Chongpeng
JM
中国
1 Years

Technical Parameter

ModelRated load (kn)Average Speed of Rope (m/min)Capacity of Rope(m)Rope diameterMotor Power(kw)Overall Dimension(mm)Total Weight(kg)








JM10100817030222090*1475*9563000
JM10B1009.525021.5221705*1598*9853500
JM12.5125830034302880*2200*15505000
JM13.5135829028222990*2362*16506500
JM161601050037373750*2400*18508800
JM202001060043453950*2560*19509900
JM25250970048554350*2800*203013500
JM32320970056754500*2850*210014800
JM50500980065904930*3050*225019500
JM6565010.53600641605900*4680*320046000



Features
Precision needle bearing used in high-load areas offering lower friction level and longer life.
High impact case providing weather resistance and protection for internal components.
Durable hook safety snap keeping the loads attached.
Gear reducer driving type.
It could lift, drag and drop vertically.
Rope arranged orderly, safe and reliable on performance.
Gear reducer driving type.
JM electric capstan winches are gear reducer driving, which is mainly used for hoisting pull and unloading tow the heavy weight.
