European Standard Single Girder Overhead Crane – CE Certified & Safe Operation
$5000.00 1 set
Qingdao Shanghai
L/C T/T
New
LD
CE, ISO9001
non
General manufacturing,Metal production industry,Renewable energy industry
10 Ton Remote Control Single Girder Workshop Eot Overhead Bridge Crane
| Widely used heavy duty light weight overhead crane is used when heavier loads,wider spans or higer working frequency are required. This kind of crane is widely used in plant, workshop and warehouse for material lifting and moving. |
| Safety Features | Advantages |
|
|
| No. | Item | No. | Item |
| 1 | Limit Switch | 1 | Short-circuit protection |
| 2 | Interlock protection device | 2 | Uner-voltage protection |
| 3 | Buffer | 3 | Zero protection |
| 4 | Rail tongs,Anchor device | 4 | Motor overhead protection |
| 5 | Rail clear plate | 5 | Emergency stop system |
| 6 | Protective cover | 6 | Current overhead protection |
| 7 | Bus bar preventer plate | 7 | Security chain protection |
| 8 | Anti-collision device | 8 | Ground protection |
| 9 | Overhead Limiter | 9 | Main isolating switch |
| Main Girder and Carrier beams |
|
Technical date (1-10 ton electric single girder bridge crane)
| Crane traveling mechanism | Traveling speed m/min | 20 | 30 | 45 | 60 | 75 | |
| Speed rate | 58.78 | 39.38 | 26.38 | 19.37 | 15.88 | ||
| Motor | Model | ZDY21-4 | ZDR12-4 | ||||
| Power kw | 2*0.8 | 2*1.5 | |||||
| Rotation speed | 1380 | ||||||
| Lifting mechanism (electric hoist ) | Model of electric hoist | CD1 MD1 | |||||
| Lifting speed m/min | 8 0.8/8 | ||||||
| Lifting height m | 6.9.12.18.24.30 | ||||||
| Trolley traveling | Traveling speed m/min | 20/30 | |||||
| Model of traveling motor | Taper sqirrel-cage | ||||||
| Working duty | A3-A5 | ||||||
| Power supply | 3ph 380v 50hz | ||||||
| Wheel diameter mm | 270 mm | ||||||
| Track surface width | 37-70mm | ||||||
Our addvantage :
Customizing according to every client .
Our cranes are exported to all over the world
Double girder overhead crane in Hongkong,Bangladesh,Tunisia ,Saudi Arabia,in Uzbekistan,
JIb crane project in Australia ,Hungary,Bahrain
Single girder overhead crane in USA ,India ,Kazakhstan,Malta
Lifting equipment in Pero ,Ireland,Holland ,Malta ,Singapore,Philippines,Argentina,Paskistan ,in Georgia
Cast heavy duty double bridge crane in Bangladesh . in Georgia
Crane parts in Saudi Arabia ,Indonesia,Vietnam,UAE ,
Gantry crane project in indonesia,kenya,Tanzania
Our service :
Delivery date | In 25 working days after received the deposit and comfirmed designs |
Payment |
30% down payment through T/T within 2days after signing the contract. 70% balanced payment after inspection before delivery from factory by T/T
|
Validity | 7 days |
Warranty | 12 months after commissioning at site or 18 months after delivery, what occurs first. During this period, we will bear all repair and maintenance expenses including broken spare parts and man power if it is caused by the defects of products itself. |
Shippment | By sea |
Installation service | Our engineer to site for installation, customers need to supply the VISA,Round trip tickets, accommodation and meals for them, and pay USD$150 per day for each person. |
Customer vist
Feedback :
Shipment :
FAQ :
In order to offer you the exact price ,
Pleas kindly confirm these information in order to offer you an exact quotation when you inquiry .
For overhead crane type
1.Do you need single girder overhead crane or double girder ?
2.Lifting capacity ?
3.Span ?
4.Lifting height ?
5.Traveling length ?
6.Power supply __v ____hz ___phase ?
7.What is the crane working condition ?
How many hours for continuous working of the crane on day ?
8.Operation method ?
A: pendent controller with push buttons.
B: remote control
C: cabin
9. Do you need us provide rail ways ? if yes , how long is the crane traveling ?
10.FOB or CFR price ? Your port of destination ?
