IP54 water resistant electric chain hoists for 1 to 10 ton outdoor use
$660.00 1 set
Qingdao Shanghai
L/C T/T
New
HHBB
CE, ISO9001
JCYC/OEM
General manufacturing
Product Description
1. Electric motor partial outer cover
They are made of high strength aluminum system through compression casting formation.
Features: Solid and light, Fast release heat, Continuous use, Enclosed structure. Can be used in the chemical plants, electroplating factories, and other places.
2. Side kind braking
This masterly structure ensure the hoist absolutly safty when the power off. And ensures it is safe when has excess load. Also it combine to the motor braking as the double brake system to strengthen security and durability.
3. Gear
The gear made of alloy steel and through the heat treatment
4. Antiphase protector
Advatages: When power-supply wiring mistake, the control circuit is unable to move.
5. Hooks
They are made by hot forging and heat treatment.
6. Chain
It is made of FEC80 ultra strong heat treatment alloy steel.
Advatages: It is safely approximately when used in the rain water, the sea water, under the chemical and other bad conditions.
7. ISO: M5 /FEM: 2AM Insulation grade: F
8. Protection class (hosit and push button): IP55
Detailed Photos
Direction for use
Electric chain hoist using range is very widely, can match with single beam, bridge crane, gantry crane, hanging on the crane can be used with single beam I iron. It can also be used with double beam trolleys. Therefore, electric hoist is one of the commonly used lifting equipment in factories, like mines, ports, warehouses, freight yards and stores, as well as the necessary machinery for improving labor efficiency and working conditions.
Product Parameters
| Technical data(single speed) | ||||||||||
| Model | Sk0.25 | Sk0.5 | Sk1 | Sk1.5 | Sk2-1 | Sk2-2 | Sk2.5 | Sk3-1 | Sk3-2 | Sk5 |
| Capacity(t) | 0.25 | 0.5 | 1 | 1.5 | 2 | 2 | 2.5 | 3 | 3 | 5 |
| Lifting speed(m/min) | 9.2 | 8.3 | 6.3 | 8.5 | 6.9 | 3.2 | 6.6 | 6.6 | 4.2 | 3.3 |
| Motor power(kw) | 0.56 | 0.9 | 1.5 | 3.0 | 3.0 | 1.5 | 3.0 | 3.0 | 3.0 | 3.0 |
| No.of chain | 1 | 1 | 1 | 1 | 1 | 2 | 1 | 1 | 2 | 2 |
| Spec.of load chain | 4.0mm | 6.3mm | 7.1mm | 10.0mm | 10.0mm | 7.1mm | 11.2mm | 11.2mm | 10mm | 11.2mm |
| Technical data(frequency transformer) | ||||||||||
| Model | Sk0.25 | Sk0.5 | Sk1 | Sk1.5 | Sk2-1 | Sk2-2 | Sk2.5 | Sk3-1 | Sk3-2 | Sk5 |
| Capacity(t) | 0.25 | 0.5 | 1 | 1.5 | 2 | 2 | 2.5 | 3 | 3 | 5 |
| Lifting speed(m/min) | 0.92-9.2 | 0.83-8.3 | 0.83-8.3 | 0.85-8.5 | 0.69-6.9 | 0.32-3.2 | 0.66-6.6 | 0.66-6.6 | 0.42-4.2 | 0.33-3.3 |
Packaging & Shipping
