Box Type Double Beam Gantry Crane, 150 Ton & 30m Span for Export

MG type double beam gantry crane ranging from 30 tons to 500 tons

Characteristics of gantry crane:

1) Reasonable structure
2) Good performance
3) Smooth start and stop
4) Safe and reliable travel
5) Low noise, spacious cabin, and good visibility
6) Easy maintenance, excellent interchangeability of parts and components
7) Energy saving specifications

• 1.The MG type double beam gantry crane consists of a gantry, a crane, a trolley walking mechanism, a cab, and an electronic control system. The gantry is a box shaped structure, with tracks on the side of each beam.

• The legs are divided into type A and type U according to user requirements. The control methods can be ground control, remote control, cabin control, or a combination of both.

• There are adjustable seats, insulation pads on the floor, tempered glass windows, fire extinguishers, electric fans, air conditioning and other auxiliary equipment in the cab. Sound alarms and walkie talkies can be provided according to user requirements.

• This double beam gantry crane has a beautiful design and is durable.

• It is widely used in outdoor warehouses and can also be used indoors.

• However, please let us know the situation in your workshop.

• Just tell us your requirements, and we can design the most suitable crane for you.

•

  capacity			T	3	5	10	16
  span			m	12,16,20,24,30
  Operation method				Suspension line with button/cabin/remote control
  speed	improve			8 ,8/0.8	8,8/0.8	7,7/0.7	3.5
  	Cross travel		m/min	20	20	20	20
  	Long distance travel	ground		20	20	20	20
  		passenger cabin		20, 30,45	20, 30,40	30,40	30,40
  motor	improve		Type/kw	ZD41-4/4.5	ZD141-4/7.5 ZDS10.8/4.5	ZD151-4/13 ZDS11.5/4.5	ZD151-4/13
  				ZDS1-4/0.4/4.5
  	Cross travel			ZDY12-4/0.4	ZDY121-4/0.8	ZDY21-4/0.8 × 2	ZDY121-4/0.8 × 2
  Electric hoist			model	CD1/MD1	CD1/MD1	CD1/MD1	CD1
  Lifting height			m	6,9,12,18,24,30
  job responsibilities				A3
  power supply				380V 60HZ three-phase AC power (according to your needs)

• The product meets the technical requirements of various types of hydraulic cranes, including general bridge cranes, gantry cranes, eot cranes, general gantry cranes, rubber tire and rail mounted container gantry cranes, four-bar gantry cranes, grab bucket cranes, boom cranes, marine deck cranes, electric hoists, electric winches, mobile platforms, etc., in industries such as factories, workshops, ports, mines, waste disposal, cargo dispersion, petrochemicals, aerospace, and military.
