Outdoor-Rated Stage Chain Hoist with IP54 Protection for All-Weather Rigging
$396.00 1 set
Qingdao Shanghai
L/C T/T
New
HCH
CE, ISO9001
HUGO
General manufacturing
The Introduction of Stage Hoist Electric Hoist
1) 2m/min for single chain
2) symmetrical structure
3) rain-proof design
4) steel-made cover
5) Friction overload protection
6)36V indirect control
7) limit switch of screw tpye
8) 100% test before assembling and loading
9) Warranty: 1 Year
Stage electric chain hoist Technical parameter
| Capacity(KG) | Model | Power(kw) | No. of load chain | Lift speed(m/min) | Weight of hoist without load chain(kg) | Weight of Load chain(Kg/m) |
| 500 | M6-W0.5A | 0.42 | 1 | 4 | 30 | 1.1 |
| 500 | M6-W0.5B | 0.86 | 1 | 8 | 48 | 1.1 |
| 500 | M6-W0.5C | 0.83 | 1 | 4 | 48.5 | 1.1 |
| 1000 | M6-W1A | 1.5 | 1 | 8 | 50 | 1.1 |
| 1000 | M6-W1B | 0.86 | 2 | 2 | 52 | 2.2 |
| 2000 | M6-W2A | 1.5 | 2 | 4 | 54 | 2.2 |
| 2000 | M6-W2B | 1.5 | 1 | 16 | 50 | 1.1 |
Features:
1) Forging steel structure small electric hoist, plastic coating cover
2) Overload Protector is available, insulation is F grade. Single use or multiple operating with one control cabinet.
3The anti phase relay device protects machine from damage when power connection is in wrong way.
4) Dual brake system -electromagnetic brake and mechanical brake. Electromagnetic brake system, using non-asbestos brake linings to reduce maintenance times greatly. 5) 24/36V Low Voltage Control: The low voltage control can protect operators from electrical shocks.
6) The surface of chain is dealted with case carburization . The inside material is softened.It is resistant to corrosion, rain, water, sea water, chemical and other bad conditions.
7) Friction overload protection
8) 36V indirect control
9) limit switch of screw tpye
10) 100% test before assembling and loading
11) you can hang upside down can also be positive.
12) Simply use the hooked end of the chain hung beam, while the lower hoist objects together along with the chain was hanging up crawling to a predetermined height, we have power after sale service system,you can believe us.
